4~12 Persons Marine Inflatable Liferaft ISO9650 Leisure Life Raft
4~12 Persons Marine Inflatable Liferaft ISO9650 Leisure Life Raft1. Description of life raftY type inflatable life raft are designed by ourselves. They are in accordance with ISO9650-1: 2005 and be approved by GL. They can be used by leisure activating small craft up to 24m length of hull as life sa......
Send Inquiry
Product Description
4~12 Persons Marine Inflatable Liferaft ISO9650 Leisure Life Raft
1. Description of life raft
Y type inflatable life raft are designed by ourselves. They are in accordance with ISO9650-1: 2005 and be approved by GL. They can be used by leisure activating small craft up to 24m length of hull as life saving equipment.
2. Application of ISO9650 Leisure Life Raft
It is suitable for installing ships on international voyages.
3. Product Standard
It meets the requirements of "Technical Regulations for the Statutory Surveys of Sea-going Ships Engaged on International Voyages(1999)" of P. R. C. And SOLAS 74/96 Amendment, LSA and MSC. 218(82).
4. Specification of ISO9650 Leisure Life Raft
Other type of Liferaft
MES Marine Evacuation System
Our Certification
Welcome to contact us for details if you are interested in ISO9650 Liferaft, other types of liferaft or Marine Evacuation System, Escape Chute.
1. Description of life raft
Y type inflatable life raft are designed by ourselves. They are in accordance with ISO9650-1: 2005 and be approved by GL. They can be used by leisure activating small craft up to 24m length of hull as life saving equipment.
2. Application of ISO9650 Leisure Life Raft
It is suitable for installing ships on international voyages.
3. Product Standard
It meets the requirements of "Technical Regulations for the Statutory Surveys of Sea-going Ships Engaged on International Voyages(1999)" of P. R. C. And SOLAS 74/96 Amendment, LSA and MSC. 218(82).
4. Specification of ISO9650 Leisure Life Raft
Type | Y-4 | Y-6 | Y-8 | Y-10 | Y-12 | |
| Physical form | Rectangular octagon | |||||
| Capacity | 4 | 6 | 8 | 10 | 12 | |
| Length(mm), ±1000 | 1700 | 1990 | 2255 | 2490 | 2730 | |
| Width(mm), ±1000 | 1700 | 1990 | 2255 | 2490 | 2730 | |
| Height(mm), ±50 | 1200 | 1250 | 1400 | 1400 | 1400 | |
| Packing dimension | Soft packing | 360×710 | 410×720 | 410×720 | 410×820 | 440×870 |
| Hard packing | 760×485×360 | 765×530×370 | 765×545×380 | 815×560×390 | 915×560×370 | |
| Weight, kg≤ | Soft packing | 35 | 41 | 45 | 49 | / |
| Hard packing | 41 | 49 | 54 | 58 | 65 | |
Other type of Liferaft
MES Marine Evacuation System
Our Certification
Welcome to contact us for details if you are interested in ISO9650 Liferaft, other types of liferaft or Marine Evacuation System, Escape Chute.
